MX-Sensor Universal Programmable Sensor

# Combines 315MHz & 433MHz frequencies into a single sensor.

# 98% vehicle coverage.

# The exclusive MX-Sensor patented PRESS release valve allows rubber and metal valve stems to freely interchange by hand without requiring a tool.

# Built to match or exceed OEM sensors in frequency strength and durability.

# 100% ID clone-able with no relearn required.

# Quickly update during installation with an Autel wireless programming tool.



TPMS Tool / Sensor Kit

# Kit Contents:

# TS508 TPMS Tool.

# 12 MX-Sensors w/ Rubber Stems.

# 4 Metal Valve Stems.

# OBDII Cord.

# Charging Cord.

# Magent.

# User Manual.

# Blow Molded Case.

# TS508 Tool includes free software updates.


Maxi TPMS DIagnostic Tool

# Activate all known TPMS sensors and read sensor status.

# Disagnose ECU for complete TPMS health check with DTC description.

# Read DTCs from ECU and erase DTCs.

# Program MX-Sensors by copying original sensor IDs or creating new IDs randomly.

# On-tool relearn procedure and wide OBD relearn coverage.

# Equipped with 7-inch touch screen with 1024x600P resolution and a VCI mini for wireless communication with the test vehicle.


4070 Series Single-Stage Center-Post Tire Changer

1150 Series Coats Wheel Balancer

# Power reverse functionality.

# Rebuildable and serviceable cylinder.

# Higher operating torque of 900 ft-lbs for more power.

# Increased rim capacity of 10"-18".

# Single bead loosener shoe for easier positioning.

# Lower anti-rotation pin for ease of use.

# Direct balancing mode selection.

# Auto hood start.

# Match balance.

# Behind-the-spoke.

# Automatc distance and diameter entry.

# Direct tape-a-weight placement.

# Increased capacity - up to 30" rim and 44" max tire diameter.


ProBalance™ V2000: High Volume, Premium Wheel Balancer

Economy Balancer

# High Volume, Direct Drive Wheel Balancer: Ships and remains calibrated to zero.

# Industrial Touchscreen: "Error-prevention" interface and progressive guided operations.

# "No Touch" Interface: for clip/clip and clip/tape balances (approximately 85% of balances).

# Enhanced Residual Imbalance Minimization: Delivers a more accurate balance.

# Integrated Laser Guided Weight Placement™ for "pinpoint" accuracy.

# Note: Adapter set not included.

# Ascot No. 481-00200

# Ideal balancer for cost-conscious shops and service stations performing fewer than 20 balancing jobs per day.

# Handles standard OEM tires up to 40" diameter and 100lbs.

# Digital readouts and data entry.

# Ten balancing modes: dynamic, alloy and static-ensure accuracy.

# Cycle time is just 10 seconds.

# Note: Adapter set not included.

# 110V, 1PH

# Ascot No. 481-00775



70X Series Rim Clamp Tire Changers

# With complete robotics and exclusive Rim Clamp® for run-flat tire changing speed and power..

# Robotic arm used to assist in top bead mounting of stiff sidewall, low profile and run-flat tires.

# Manual bead roller used to assist in holding the tire bead down to lube both the tire and wheel.

# Robotic arm used to hold tires in the up position to reduce the effort in second bead removal.

# Handles up to 22" wheels clamping with option for 24" wheels.

# Also available in electric versions.

# Ascot No. 443-70183

Important Sites
Product Spotlight
  1" Heavy Duty Air Impact Wrench - #CP7782-6
Pinless closed reinforced rockign dog impact mechanism.

Socket retainer ring combined with hole retainer.

Ergonomic side handle.

Full teasing trigger with 6 inch extended anvil.

Regulator with integrated forward/reverse 3-position power settings in BOTH directions.

2,140 ft./lbs. 2,900 Nm of maximum torque in reverse.

Product Number: CP7782-6

Latest Products


//Product 1a //Product 2a //Product 3a //Product 4a //Product 5a //Product 7a //Product 8a //Product 9a //Product 10a //Product 11a //Product 12a //Product 13a //Product 14a //Product 15a //Product 16a //Product 17a //Product 18a //Product 19a //Product 20a //Product 21a //Product 22a //Product 23a //Product 24a //Product 25a //Product 26a //Product 278a //Product 28a



//Product 1b //Product 2b //Product 3b //Product 4b //Product 6b //Product 7b //Product 8b //Product 9b //Product 10b //Product 11b //Product 12b //Product 13b //Product 14b //Product 15b //Product 16b //Product 17b //Product 18b //Product 19b //Product 20b //Product 21b //Product 22b //Product 23b //Product 24b //Product 25b //Product 26b //Product 27b //Product 28b


Product Spotlight
  SMART Tire Cart
"Patent Pending."

Works on passgener 15in tires up to truck size 245/70R19.5 tires.

Moves mounted tiresl and wheel sets.

Stacks tires closer together than other carts which creates more storage space.

Great for loading and unloading trucks and containers.

No foot pedals.

Patented tilting action relieves stress off the user.

New push/pull system pushes the tires out of the SMART Cart arms without stress.

Fewer moving parts. Easy to assemble.

Ascot No. 703-47147

Product Spotlight
  Winntec Tire Dolly
500lbs. capacity allows for use on all commerical truck tire sizes.

Steel frame is more durable than Aluminum units.

Longer rollers makes it even easier to handle super single sizes.

Wheel position allow tech to lift tire/wheel assembly by pushing down, instead of lifting up.

O-LINE-ER and Bracket included with new production models!

Ascot No. 407-47105
